| 型號 | FSCAN-
2080 | FSCAN-
3280/3280C | FSCAN-
4280/4500/4500H | FSCAN-
6280/6500/6500H |
| Minimum detection capability | Lead(Pb)0.2mm, Fe sphere ?0.28 |
| SUS wire ?0.28 x 1mm |
| X-ray Output | Max.80kV | Max.80kV | Max.80kV/120kV | Max.80kV/120kV |
| 100W | 100W | 100W/480W | 100W/480W |
| Conveyor | Detection speed | Max. 60m/分 | Max. 60m/分 | Max. 60, 43m/分 | Max. 43m/分 |
| Min. 10m/分 | Min. 10m/分 | Min. 10m/分 | Min. 10m/分 |
| Width | 195mm | 270mm | 420mm | 620mm |
| Maximum passage height | 120mm | 145mm | 175mm/190mm/250mm | 300mm/405mm |
| Maximum weight | 10kg(5kg以下 Belt速度：每分 40M/min以上) (可選20kg) |
| Height of belt surface | 750 ± 50mm |
Control
computer
Monitor | Core 2 Duo E2200 2.2G (RACK TYPE) |
Operation
System | Window XP Professional |
| Management of images of defectiveness | 存儲于USB port，可以輸送(應對HACCP) |
| Masking function | 產品形狀，圖像亮度掩蔽功能(共16種)/最大10,000個 |
| Model registration function | 可以進行產品登錄(應對HACCP) |
| Product Management | Daily/Month/Model Product Capacity Analysis |
| Equipment Management | MTBF, MTTR, Error Log, Error Analysis |
| Teaching | Auto Teaching, Manual teaching |
| Image Management | Image Save/ Print/ Analysis(Defect Size measurement) (應對HACCP) |
| Washing | In accordance with IP66 Standard base |
| Amount of x-ray exposure | 最大輸出量 < 10uSv/Hour |
| Operational environment | 0°C ~ 35°C |
| Power supply/product weight | 220V 單相, Max.200kg | 220V 單相, Max.320kg | 220V 單相, Max.480kg | 220V 單相, Max.580kg |
| External dimensions | 1420*767*685 mm (H*W*D) | 1520*870*735 mm (H*W*D) | 1700x1400x775mm (HxWxD) | 1800x1900x1100mm (HxWxD) |
| Power consumption | 1.2kw | 1.2kw | 1.2kw | 1.5kw |
